Model | Junda-J009 |
Chemistry | LiNiCoMnO2 |
Nominal Voltage | 48V |
Nominal Capacity | 17.5Ah |
Weight | Approx 5.5Kg |
Outer case | black case |
Dimension | 110*90*360mm |
Standard Charge | Constant Current 0.2C, Constant Voltage 54.6V 100mA Cut-off |
Fast Charge | Constant Current 0.5CA, Constant Voltage 54.6V 100mA Cut-off |
Standard Discharge | Constant Current 0.2C/End Voltage 39V |
Cycle Life | 500 times with DOD80% |
Continuous Discharge Current | 17.5A or customized |
Peak discharge current | 52.5A or customized |
BMS function | Over-Current Protection,Over-Discharge Protection, Over-Charge Protection,Short-Circuit Protection, Balance |
Storage Temperature Range | Temperature: -10-40℃ Relative humidity:45-75% Pressure: 86-106KPa |
